DN800-5R5G1

DN800-5R5G1

HEAVY-DUTY VECTOR FREQUENCY CONVERTER

DN800/900 series adopts an int egrated IGBT module for all models, which

provides better performance and higher reliability;

Double row LED display on the panel, with direct dual display of on-site voltage,

fixed frequency, and operating current, making it clear at a glance.

Adopting a new generation of high-speed motor control DSP, and innovating the

use of a multi-core processing technology platform,ultra-high speed computing

ensures the complete realization of Funa's vector calculation;

No PG vector control, using advanced motor model algorithm to achieve open

torque control with algorithm, torque response of 10ms,

stable accuracy<5%, word speed ratio of 1:200, s table installation speed accuracy

of 0.2%, and output 180% rated torque at 0.5HZ;

Comprehensive flow, pressure, load suppression, and stall prevention functions;

Complete self powering function, wide voltage range.


0.00
0.00


HEAVY-DUTY VECTOR FREQUENCY CONVERTER

DN800/900 series adopts an int egrated IGBT module for all models, which

provides better performance and higher reliability;

Double row LED display on the panel, with direct dual display of on-site voltage,

fixed frequency, and operating current, making it clear at a glance.

Adopting a new generation of high-speed motor control DSP, and innovating the

use of a multi-core processing technology platform,ultra-high speed computing

ensures the complete realization of Funa's vector calculation;

No PG vector control, using advanced motor model algorithm to achieve open

torque control with algorithm, torque response of 10ms,

stable accuracy<5%, word speed ratio of 1:200, s table installation speed accuracy

of 0.2%, and output 180% rated torque at 0.5HZ;

Comprehensive flow, pressure, load suppression, and stall prevention functions;

Complete self powering function, wide voltage range.


DN800/900 SERIES

TECHNICAL PARAMETERS


Application Industry: Textile equipment, ceramic equipment, water supply equipment, printing equipment, stone equipment, food equipment, fan equipment,conveyor

belt equipment, wood working equipment, industrial washing machine, ect.


ModelInput Power
    Source
Power capacity
    (KVA)
Input current
    (A)
Output current
    (A)
Adapted motor
(kW)(HP)
 DN800-0R75G1Single-phase
Power Supply
220V
50Hz/60HZ
1.58.22.50.751
 DN800-1R5G13144.11.52
 DN800-2R2G14235.82.23
 DN800-4R0G15.531944
 DN800-5R5G18.926135.55
 DN800-7R5G12135177.510
 DN800-0R75G21.58.240.751
 DN800-1R5G231471.52
 DN800-2R2G24239.62.23
 DN800-4R0G25.5311744
 DN800-5R5G28.926255.55
 DN800-7R5G22135327.510
 DN800-0R75S31.54.840.751
 DN800-1R5S337.671.52
 DN800-2R2S3410.39.62.23
 DN800-4R0S35.517.3173.74
 DN800-5R5S38.925.4255.55
  DN800-0R75G3Three-phase
Power Supply
380V
50Hz/60HZ
1.53.62.50.751
  DN800-1R5G335.14.11.52
  DN800-2R2G3465.82.23
  DN800-4R0G36.110.5945
  DN800-5R5G38.914135.57.5
  DN800-7R5G31121177.510
  DN900-0R75G31.53.62.50.751
  DN900-1R5G335.14.11.52
  DN900-2R2G3465.82.23
  DN900-4R0G36.110.5945
  DN900-5R5G38.914.6135.57.5
  DN900-7R5G31121177.510
  DN900-7R5G31121177.510
  DN900-11R0G31726251115
  DN900-15R0G32135321520
  DN900-18R5G32438.53718.525
  DN900-22R0G33046.5452230
  DN900-30R0G34062603040
  DN900-37R0G35776753750
  DN900-45R0G36992914560
  DN900-7R5S32132.5327.510
